Bbzx-160 Benba Dump Electric Tricycle 1.6m 1200W Flat-Wire Motor 60V/72V 500kg Rated Load 1000kg Max Load

Title: bbzx-160 Benba Dump Electric Tricycle 1.6m 1200W Flat-Wire Motor 60V/72V 500kg Rated Load 1000kg Max Load

Product Name: bbzx-160 Benba Dump Electric Tricycle

Product Description:
The bbzx-160 is a 1.6m Benba dump electric tricycle with overall dimensions of 3160×1160×1390mm and a cargo box of 1600×1100×500mm. It uses a 1200W flat-wire motor (1500W) with a 60V/72V controller and a top speed of 38km/h. Rated load is 500kg and maximum load is 1000kg. Lithium or lead-acid batteries are optional. Suitable for short-distance cargo transport and dump work.

Key Features:
• 1200W flat-wire motor, 60V/72V controller, 38km/h top speed
• 1.6m dump cargo box, 500kg rated load, 1000kg maximum load
• Front and rear drum brakes plus hand parking, 6m braking distance
• One-line control, hill hold, HDC, 3-speed high/low shift

Product Specifications:
Model: bbzx-160
Product Type: 1.6m Benba Dump Electric Tricycle
Overall Size: 3160×1160×1390mm
Cargo Size: 1600×1100×500mm
Cargo Material: 1mm steel cargo floor
Curb Weight: 298kg
Rated Motor Power: 1200W Flat-Wire Motor (1500W)
Controller: 60V/72V
Rear Axle: Integrated Full-Floating Rear Axle, Φ180 Brake Drum
Front Fork: Φ37 Outer Spring Hydraulic Shock Absorber
Tires: Front 400-12, Rear 400-12, 8P Steel-Belted Wire Tires
Rims: Heavy-Duty Steel Wheels
Brake Mode: Front/Rear Drum, Hand Parking
Brake Distance: 6m
Wire Harness: 6mm² National Standard
Spring Plate: 5pcs × 8kg × 2 sets
Wheelbase: 980mm
Track: 1980mm
Max Gradeability: ≥15°
Max Speed: 38km/h
Rated Load Capacity: 500kg
Max Load Capacity: 1000kg
Battery: Lithium / Lead-acid Optional
Meter: LCD Digital Display
Lights: LED Headlight and Taillights, Waterproof Plug
Rearview Mirror: Adjustable Wide-Angle Mirrors
Speaker: Chinese / English / Russian / Reversing Beep (Customizable)
Functions: One-Line Control, Hill Hold, HDC, 3 Speed Modes, High/Low Speed Shift, P Gear
Optional: Music Box, Remote Control Key, Anti-Theft Beep, Range Extender, Phone Holder
Loading Qty: SKD 42 Units / 40HQ, CKD 48 Units / 40HQ
Suitable For: Short-distance cargo transport, Dump work, Park logistics
